| Nominal Cross Sectional area of conductor (SQ. MM) |
Number/ Nom. Dia of cond. strands (MM) |
Thickness of Insulation (Nom) (MM) |
Thickness of Sheath (Nom) (MM) |
Max. Overall Diameter (MM) |
Conduit / Trunking (AMPS) |
Max. Conductor Resistance per KM at 20ºC (OHMS) |
|---|---|---|---|---|---|---|
| 2.5 | 3/1.06 | 0.8 | 1.10 | 6.70 | 13 | 12.1 |
| 2.5 | 7/0.71 | 0.8 | 1.10 | 6.70 | 13 | 12.1 |
| 4.0 | 7/0.86 | 0.8 | 1.20 | 7.20 | 18 | 7.41 |
| 6.0 | 7/1.02 | 0.8 | 1.20 | 8.10 | 24 | 4.61 |
| 10.0 | 7/1.35 | 1.0 | 1.20 | 9.50 | 31 | 3.08 |
| 16.0 | 7/1.70 | 1.0 | 1.30 | 10.60 | 42 | 1.91 |
ZENFLEX was established in the year 1990 to manufacture wires and cables for domestic and industrial use.
