Three Core Flat Hrfr Pvc Insulated Industrial Grade Cable For Submersible Use, 1100 Volts
FEATURES OF ZENFLEX 3 CORE FLAT SUBMERSIBLE CABLE
Outer sheath consists of a highly abrasion-resistant PVC compound impervious to grease, oil, and water, etc.
Good insulation properties even when submerged in water.
High mechanical & electrical properties that ensure easy installation and long life.
Progressive sequential length marking on every meter
| Nominal area of conductor (SQ. MM) |
Number/Size of wire for each core (MM) |
Thickness of Insulation (Nom) (MM) |
Thickness of Sheath (Nom) (MM) |
SHEATH Approx Overall Dimension Width (W) (MAX.) MM |
SHEATH Approx Overall Dimension Height (H) (MAX.) MM |
Max. Conductor Resistance at 20°C (Max) (OHMS / KM) |
Current Carrying Capacity at 40°C (AMPS) |
|---|---|---|---|---|---|---|---|
| 1.50 | 22/0.30 | 0.6 | 0.9 | 12.0 | 5.6 | 12.1 | 13 |
| 2.50 | 36/0.30 | 0.7 | 1.0 | 13.0 | 6.2 | 7.41 | 18 |
| 4.00 | 56/0.30 | 0.8 | 1.0 | 15.3 | 7.0 | 4.95 | 24 |
| 6.00 | 84/0.30 | 0.8 | 1.1 | 19.2 | 8.4 | 3.30 | 31 |
| 10.00 | 80/0.40 | 1.0 | 1.4 | 24.2 | 9.8 | 1.83 | 42 |
| 16.00 | 126/0.40 | 1.0 | 1.4 | 29.2 | 12.4 | 1.21 | 57 |
| 25.00 | 196/0.40 | 1.2 | 2.0 | 36.5 | 15.7 | 0.78 | 72 |
